    30T Stone Coated Roof Tile Machine CE Production Line

    Ask Lasest Price
    Brand Name : Gracias
    Model Number : stone coated roof making machine
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10sets per month
    Delivery Time : 50-70 work days
    • Product Details
    • Company Profile

    30T Stone Coated Roof Tile Machine CE Production Line

    30T Stone Coated Roof Tile Machine CE Production Line


    Processing flow diagram stone coated step roof machine


    Flattening-Slitting-CuttingTrimmingPressingAutomatic bottom glue spraying equipment

    Automatic Sandblasting RoomFirst drying roomAutomatic surface glue spraying equipment

    Second drying room equipment component


    Component and Details


    (1)Automatic bottom glue spraying equipment,

    Outside Dimension4000 × 1350 × 850mm(L*W*H)
    Transmission2.2kw,variable-frequency,adjustable-speed,motor0-32R/Min
    Conveying deviceBeciprocating chain conveys
    Automatic glue spraying assemblywith motor 0.06kw
    Adsorption of dust removal equipment1 set
    Air compressor1 set 0.9m
    Automatic pressure glue canister1 set range of adjustable pressure 0.1-0.6MPa
    Automatic glue spraying gun4 sets
    Fill glue gun5 sets
    Glue gun stand1 set

    (2)Automatic sandblasting room ,

    Outside Dimension3000 ×1850 ×700mm(L*W*H)
    TransmissionWith glue spraying equipment compound chain transmit
    Conveying deviceCompound chain transmit
    Automatic sand hopper1 set dimension 550*600*500mm
    Automatic rising machine1 set with rising height 1.9m power 300kg/h
    Sun-blasting gun4 sets

    (3)First drying room,

    Outside Dimension25000 ×800 ×1200mm(L*W*H)
    Frame type heat preservation wallFill up with heat preservation material which is bended with 1mm carbon steel
    Automatic temperature controller2 sets,range of adjustable temperature 0-160°C
    Infrared fluorescent tube50 pcs
    Conveying deviceReciprocating chain conveys
    Cooling device1 set

    (4)Automatic surface glue spraying equipment,

    Outside Dimension3000 ×850 ×700mm(L*W*H)
    Automatic glue spraying gun2 sets
    Automatic spraying assembly1 set range of pressure 0.1-0.6MPa
    Adsorption of dust removal equipment1 set
    Manual spraying gun5 sets

    (5)Second drying room equipment,

    Outside dimension30000 ×850 ×700mm(L*W*H)
    Frame type heat preservation wallFill up with heat preservation material which is bended with 1mm carbon steel
    Conveying deviceReciprocating chain conveys
    Infrared heat tube50 pcs
    Automatic temperature controller2 sets,range of adjustable temperature 0-160°C
    Conveying deviceReciprocating connection conveys 30m
    Cooling device1 set
    Automatic printing code and marking1 set of automatic printer
