ISO Stone Coated Roof Tile Machine , 30T Manual Roof Tile Making Machine

ISO Stone Coated Roof Tile Machine 30T Manual Roof Tile Making Machine

1. Processing flow diagram FX stone chip coated metal roof tile sheet roll forming machine

Flattening-Slitting-Cutting→Trimming→Pressing→Automatic bottom glue spraying equipment

→Automatic Sandblasting Room→First drying room→Automatic surface glue spraying equipment

→Second drying room equipment component

2. Technical parameters

Leveling-Slitting-Cutting Machine

1.Flattening-Slitting-Cutting Machine

1. 5t manual decoiler

2. aa: 45# steel, outer diameter 85mm

3. Number of shaft: feeding step: 1 piece

4. Leveling: up: 5 pieces, down: 6 pieces

5. Blade material: Cr12 steel with quenched treated 60-62°C

Automatic Bottom Glue Spraying Equipment

1. Closed automatic spraying glue system

2. Outside Dimension:4000*1350*850mm(L*W*H)

3. Structure:Channel steel ,welded

4. Conveying device:Reciprocating chain conveys

5. Adsorption of dust removal equipment:1 set

6. Air compressor: 1 set, 7.5kw, air output is 1m³/min

7. D46 high-pressure airless spraying system 1 set (German technology)

8. Automatic high-pressure airless spraying gun: 1 set (Japanese technology)

9. High-pressure airless manual spraying gun:1 set(Japanese technology)

10. Standard 15M German import high-pressure airless feed tube and it can support the maximum pressure is 20Mpa

100L stainless charging basket 1 piece

Automatic Sandblasting Room

1. Outside Dimension :3000*1850*700mm(L*W*H)

2. Structure:Channel steel ,angle steel ,welded

3. Transmission:With glue spraying equipment compound chain transmit

4. Conveying device:Compound chain transmit

5. Air compressor: 1 set, 18.5kw, air output is 3m³/min

6. High-pressure sand suction system: 1 set, sand suction is 1T/hour

7. Sand hopper: 1 set, dimension:550*600*500

8. Automatic shaking sand system: one cylinder, the motor with 0.75kw, control: PLC

First Drying Room

1. Outside Dimension:4000*1350*850mm(L*W*H)

2. Structure:Channel steel ,welded

3. Conveying device:Reciprocating chain conveys

4. Adsorption of dust removal equipment:1 set

5. Air compressor: 1 set, 7.5kw, air output is 1m³/min

6. D46 high-pressure airless spraying system 1 set

7. Automatic high-pressure airless spraying gun: 1 set

8. High-pressure airless manual spraying gun:1 set

9. Standard 15M German import high-pressure airless feed tube and it can support the maximum pressure is 20Mpa

10. 100L stainless charging basket 1 piece

Automatic Surface Glue Spraying Equipment

1. Outside Dimension :30000*850*700mm(L*W*H)

2. Structure:carbon steel welded

3. Frame insulation wall: 30 meters’ long, 1mm carbon steel plate bending forming filled with cotton insulation

4. Automatic temperature controller:2 sets,Range of adjustable temperature:0-160°

5. Infrared fluorescent tube:50 pieces

6. Conveying device: Reciprocating chain conveys 30m

7. Cooling device:1 set

8. Total equipment matches total control station 2 sets (Control system)

9. Productivity:3-6m/min Calculate as 1.2m per piece,eight hours,produce 1500pcs every day

10. Whole machine power:130kw
