Cold Steel Cable Tray Roll Forming Machine 15m/min 6T

Hydraulic cutting

Cutting type: hydraulic cutting
Blade type: close type die cavity cutter
Hydraulic power:5.5kw
Material of blade: Cr12, quench treatment, hardness HRC56-58
Quantity: 9 (depend on customer request)

Parameter: width of material: 225-1020mm thickness: 1-2mm;
Inner diameter of coil: 508mm;inner expansion range: 480-520 mm;
The maximal of Diameter: 1500mm; The Maximal of loading: ≤6T
Motor power: 5.5kw frequency change control
Press material type: pneumatic press material
Feeding speed: 12-15m/min, adjustable

The company's main products are: Steel door Embossing machine, Roof sheet roll forming machine, Glazed tile roll forming machines, Stud & track roll forming machine, Highway guardrail roll forming machine, Purlin roll forming machine,Roller shutter door roll forming machine, Sandwich panel roll forming machine,Light steel villa roll forming machine, Rotary punching machine, Cable tray roll forming machine, and other cold roll forming machine. The company adheres to the service tenet of "quality first, credit first",  the concept of "quality is their food for enterprise ". We will provide customers with high quality products and after-sales service.
