    Large Long K Span Roll Forming Machine Vertical Decoiler 14 Steps

    Ask Lasest Price
    Brand Name : Gracias
    Model Number : ZX-914,ZX-1000
    Price : As discussion
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 45sets per month
    Delivery Time : 20-60 work days
    • Product Details
    • Company Profile

    Large Long K Span Roll Forming Machine Vertical Decoiler 14 Steps


    LARGE LONG K SPAN ROLL FORMING MACHINE


    Product intruduction:


    The model is our another large span roof forming machine, it adpots PLC controlling system,

    all the rollers are forged from the high quality structural steel and are processed intensely.

    The surfaces of the rollers are plated with hard chromium. The rollers have a high hardness

    and long operating life.


    Technical parameters:


    MAIN TYPEFEEDING WIDTHEFFECTIVE WIDTHDEPTH OF THE GROOVETHICKNESSPROPER SPANUSAGE RATE
    ZX-914-610914mm610mm203mm0.6-1.6mm7m-38m66.7%
    ZX-914-650914mm650mm181mm0.6-1.6mm7m-28m71.1%
    ZX-914-700914mm700mm123mm0.6-1.6mm7m-24m76.6%
    ZX-914-750914mm750mm86mm0.6-1.6mm7m-18m82%
    ZX-1000-6101000mm610mm243mm0.6-1.6mm10m-38m51%
    ZX-1000-7001000mm700mm175mm0.6-1.6mm7m-28m70%
    ZX-1000-7501000mm750mm138mm0.6-1.6mm7m-20m75%

    MAIN TYPEFEEDING WIDTHEFFECTIVE WIDTHDEPTH OF THE GROOVETHICKNESSPROPER SPANUSAGE RATE
    ZX-1000-6801000mm680mm223mm0.6-1.6mm10m-36m68.0%
    ZX-600-305600mm305mm109mm0.6-1.6mm4m-26m51.0%
    ZX-600-303600mm303mm109mm0.6-1.6mm4m-24m50.5%
    ZX-1250-8001250mm800mm320mm0.6-1.6mm15m-42m64%
    ZX-1220-8001220mm800mm314mm0.6-1.6mm15m-42m65.5%
    ZX-1200-8001200mm800mm285mm0.6-1.6mm15m-42m67%
    ZX-1000-8001000mm800mm114mm0.6-1.6mm6m-14m80%
